| Stripcurtains.com offers Quick-Seal Hi-Speed Doors for quick access through openings. They are designed for high volume, high speed traffic in commercial, industrial or refrigerated applications. All doors incorporate a state-of-the-art microprocessor controlled AC variable speed drive system, allowing the door to move at faster speeds than conventional doors. All roll-up doors are equipped with standard safety features for protection against injury. |
High Speed Door Demo Video (Clip #1)
Quick Seal High Speed Door
This text will be replaced
|
High Speed Door Demo Video (Clip #2)
8 Year-old door still in operation
This text will be replaced
|
- Manufacturing
- Pharmaceutical
- Cold Storage
- Transport and Distribution
- Food Processing
- General Warehousing
- Clean Rooms
|
 |
Speed |
Opening 0.8~ 1.5m/sec (adjustable); closing 0.5~ 0.8m/sec
(adjustable) |
Motor |
Turbine decelerator + brake, three-phase 220V |
Power |
three-phase 220V AC, 15A |
PVC Material |
PVC Resin 1000 den textile, 0.8mm thickness; low flammability,
dust-proof, and UV-proof |
Door Frame
Material |
galvanized steel, thickness: 2.0mm |
Safety
Equipment |
Germany safety, GS, certified electronic device, cushions installed on
the bottom edge of the door with sensor to react contacts to
obstacles. |
Airflow-proof |
Thin steel plates have been installed inside of the PVC door sheet
behind the wheels. This structure enhance the stability of the wheels
and prevents wheel degression caused by strong airflows. |
Control Panel |
With emergency rising and lowering bottoms |
Positioning
System |
Limit Switch |
Safety |
1. Photoelectric sensors installed on the side tracks, with emergency
stopping reaction when sensing obstacles.
2. Cushions installed on the bottom edge of the door with sensor to
react contacts to obstacles.
3. Control: Switches with emergency stopping reacting function.
4. Manual pulling chain when power failure is encountered." |
Sensor System |
Six options: radar sensor, infrared sensor, supersonic sensor,
photoelectric sensor, manual operating system, remote control.
Connectable to PLC, AGV, Interlock. |
|
|
